UMAX® One

With six color options, luxurious bucket seats, under hood storage compartment, and large 20" tires, you can see the difference when power, performance, versatility, and comfort matter.

See Us in Action

The Better Ride

  • Fuel System:EFI - Electronic Fuel Injection
  • ENGINE TYPE:Yamaha-built, 402 cc, low-emission single cylinder 60° incline OHV
  • LUBRICATION SYSTEM:Splash-style positive oil lubrication
  • OIL CAPACITY:1.16 U.S. quart (1.1 liter, 1100cc)
  • AIR CLEANER:Two-stage, urethane-foam pre-cleaner, and high-capacity pleated paper cartridge
  • COOLING SYSTEM:Forced Cooling
  • STARTING SYSTEM:Starter generator with pedal start system
LEARN MORE ABOUT EFI
Overall Length
111.45 in (283.1 cm)
Overall Width
49.33 in (125.3 cm)
Overall Height(with suntop)
74.02 in (188 cm)
Overall Height(without suntop)
48.54 in (123.3 cm)
Wheelbase
66.18 in (168.1 cm)
Front Wheel Tread
39.96 in (101.5 cm)
Rear Wheel Tread
40.19 in (102.1 cm)
Minimum Ground Clearance
4.56 in (11.6 cm)
FRAME
HybriCore™ chassis features a robotic welded automotive ladder-style steel frame protected with a multi-step full-immersion phosphate treatment, electro-deposition epoxy-based coating, and an electrostatic applied polyester/urethane powder topcoat.
BODY
Custom-formulated thermoplastic olefin painted with a two-part top coat of high-luster automotive-grade polyurethane.
STEERING
Self-compensating double reduction helical rack-and-pinion.
FRONT WHEEL SUSPENSION
Tru-Trak II™ fully independent automotive-style strut suspension.
REAR WHEEL SUSPENSION
Unit swing arm with DUAL RATE coil springs over hydraulic shock absorbers.
BRAKES
Self-adjusting mechanical, rear wheel drum brakes.
Maximum Forward Speed
17.5 mph (28 km/h)
Maximum Reverse speed
13.1 mph (21 km/h)
Minimum turning radius
3.5 m (11.4 ft)
Dry Weight
961.2 lb (436 kg)
CARGO BED CAPACITY
300 lbs
TOWING CAPACITY
800 lbs
CARGO BED SIZE
33.2" L x 45.9" W x 11.9" H
FUEL TANK CAPACITY (Gas)
5.2 US GAL (20 LITERS)
TIRE SIZE
20x10x10 4ply Monitor K389 (front) K500 (rear)
SEATING CAPACITY
2 persons
AVAILABLE MODEL COLORS
Glacier Metallic: Jasper, Carbon, Aqua Blue, Noble Orange, Evergreen
AVAILABLE SEAT COLOR
Black
AVAILABLE SUNTOP COLOR
Black
Standard 2-year limited vehicle warranty
