UMAX Rally®
UMAX Rally®
All-Terrain Dump Bed Utility Vehicle
The UMAX Rally combines all the great features of the UMAX with a lifted suspension, 23” tires, front brush guard and deFender fender flares. Whether its for the farm, construction site, or campus, the UMAX Rally can do it all.
- Bluestone
- Carbon
- Coral Red
- Evergreen
- Glacier
Our UMAX lineup was expertly designed to get the job done. The UMAX Two EFI combines premium power and torque to deliver the performance you need for any job big or small. If gas works best for you, then trust our EFI powertrains to fit your needs with efficiency and reliability.
| Rear Suspension | Cradle-Smooth Suspension |
| Front Suspension | Independent Front Suspension |
| Yamaha-Built Engine | 357cc, low-emission single cylinder 60° incline OHV |
| Miles Per Gallon | 45 mpg |
| Easy Access Engine Compartment | Standard |
| Additional Features | 60.5 dB reduced engine noise |
Our UMAX lineup was expertly designed to get the job done. The UMAX AC powertrain combines power and efficiency with a low cost, low maintenance electric option. Our electric power houses provide the power you need for any job with impressive towing, cargo capacities and long lasting charges.
| Rear Suspension | Cradle-Smooth Suspension |
| Front Suspension | Independent Front Suspension |
| Battery | 6 - 8V Trojan T-875 FLA |
| Toyota MCU | Standard |
| Power Production | 4.4 hp (3.3 kW) |
| Delta-Q Charger | Standard |
| Additional Features | Time tested FLA batteries |
INNOVATIVE FEATURES AT EVERY TURN
UMAX Rally® SPECIFICATIONS
- Dry Weight: UMAX One: 999.8 lb (453.5 kg), UMAX Two: 1070.3 lb (485.5 kg)
- Cargo Box Material: Aluminium
- Cargo Bed Capacity: 800 lbs.
- Towing Capacity: 1500 lbs.
- Cargo Bed Size: UMAX One: 32.8" L x 45.9" W x 11.9" H, UMAX Two: 41.1" L x 45.9" W x 11.9" H
- Fuel Tank Capacity (Gas): 5.2 US GAL (20 LITERS)
- Tire Size: 23x10.5x12 6ply
- Seating Capacity: 2
- Available Model Colors: Glacier Metallic: Jasper, Carbon, Aqua Blue, Noble Orange, Evergreen
- Available Seat Color: Black
- Available Suntop Color: Black
- Overall Length: UMAX One: 114.6 in (291.2 cm), UMAX Two: 122.6 in (311.3 cm)
- Overall Width: 53.54 in (136 cm)
- Overall Height(with suntop): 74.02 in (188 cm)
- Overall Height(without suntop): 50.70 in (128.8 cm)
- Wheelbase: UMAX One: 66.3 in (168.3 cm), UMAX Two: 77.3 in (196.3 cm)
- Front Wheel Tread: UMAX One: 40.9 in (104.0 cm), UMAX Two: 41.3 in (104.8 cm)
- Rear Wheel Tread: UMAX One: 40.9 in (104.0 cm), UMAX Two: 41.3 in (104.8 cm)
- Floor Board Height: 15.23 (387 mm)
- FRAME: HybriCore™ chassis features a robotic welded automotive ladder-style steel frame protected with a multi-step full-immersion phosphate treatment, electro-deposition epoxy-based coating, and an electrostatic applied polyester/urethane powder topcoat.
- STEERING: Self-compensating double reduction helical rack-and-pinion.
- FRONT WHEEL SUSPENSION: Tru-Trak II™ fully independent automotive-style strut suspension.
- REAR WHEEL SUSPENSION: Unit swing arm with heavy duty coil springs over hydraulic shock absorbers.
- BRAKES: Self-adjusting mechanical, front and rear wheel drum brakes.
- SEATING: 2 Persons
